Dosing System
SENSE
Sense is a multi-parametric and natively connected measuring instrument, able to control some chemical-physical parameters of the water, including pH, ORP, free / total chlorine and conductivity.
It can control up to three dosing pumps.
It can control up to three dosing pumps.
General Information
Fields of use
Public or private swimming pools
Water treatment systems
Detergency and laundry systems
Characteristics
- Integrated Wi-Fi connection
- 110-230 Vac power supply
- Access Point/Standby button to allow connection to Wi-Fi
- Luminous LED bar that facilitates the reading of the parameters and signal any errors
- Possibility of choosing the operating mode between Acid/Alkaline (pH), Oxidizing and Reducing (ORP), Direct and Inverse (CL and CD)
Technical data
| Product | N. parameters | Relay outputs | Setpoint | Temperature probes | mA outputs | Auxiliary outputs | Level probe inputs | Alarm relay | Proximity probe input | Proportional mode |
|---|---|---|---|---|---|---|---|---|---|---|
| SENSE | 1 | 4 | 2 | PT100 | 1 | 1 | 1 | 1 | Yes | Yes |
| SENSE | 2 | 5 | 3 | PT100 | 2 | 2 | 2 | 1 | Yes | Yes |
| SENSE | 3 | 6 | 4 | PT100 | 3 | 3 | 3 | 1 | Yes | Yes |
General
technical characteristics
Dimensions
Pack
Height x size x depth: 155 x 295 x 350 mm
